Model

KM-15

Rated voltage

AC220V-AC240V

Resistance （25℃）

/

Frequency

50Hz/60Hz

Contact capacity

DC5V/10mA

Electrical strength

Apply a 50/60Hz sine wave test voltage of 1500V/1 minute between the terminal and the uncharged metal part. There should be no breakdown or flashover

Insulation resistance

Insulation resistance between live part and uncharged metal part is more than  50MΩ (measured by a 500V insulation resistance meter)

Fire proof

conform to UL94-V0

Mechanical strength

Breaking open force >100N

Comparative Tracking Index

PTI250

Lock time

Immediately lock when power on

Unlock time

Immediately open when power off

Reliability

20000 cycles of lock and unlock

Terminal pin

/

Environment friendly

Conform to RoHS 2011/65/EU
